HX Series 100% Oil-Free Air Compressors
The Chicago Pneumatic HX Series 100% oil-free air compressors are designed for industries that demand absolute air purity, high reliability, and continuous performance. Built with oil-free piston compression technology, the HX Series delivers contamination-free compressed air for sensitive industrial applications where air quality is critical to product safety and process efficiency.
Available in vertical and horizontal balanced opposed piston (BOP) configurations, HX compressors are suitable for low-pressure, medium-pressure, and high-pressure applications, offering flexibility across a wide range of industrial processes.
Specifications
HX Series – Vertical and Horizontal BOP
| Model | FAD in CFM |
Working Pressure Kg/cm² |
FAD in CFM |
Working Pressure Kg/cm² |
Motor Rating (HP) |
Dimensions (MM) Approx L × W × H |
Weight (KG) Approx |
|---|---|---|---|---|---|---|---|
| Models For Low Pressure | |||||||
| HX1T 25 LP HX1T 30 LP | 162 | 4 | 184 | 2.5 | 25 30 |
2540 × 1005 × 2000 2540 × 1005 × 2000 |
1490 |
| HX2T 50 LP HX2T 75 LP | 180 | 4 | 234 | 2.5 | 50 75 |
2540 × 1005 × 2000 3050 × 1880 × 2220 |
1490 |
| / LPS HX2T 100 LP | 332 | 4 | 421 | 2.5 | 100 | 3050 × 1880 × 2220 | 3300 |
| 494 | 4 | 626 | 2.5 | 3050 × 1880 × 2200 | 3300 | ||
| 660 | 4 | 781 | 2.5 | 3300 | |||
| Models For Medium Pressure | |||||||
| HX1T 15 NP | 42 70 | 10 | 60 86 | 7 | 15 | 2540 × 1005 × 2000 | 1290 |
| HX1T 20 NP | 95 | 9 | 114 | 7 | 20 | 2540 × 1005 × 2000 | 1290 |
| HX1T 25 N2P/N2PS | 112 | 9 | 136 | 7 | 25 | 2540 × 1005 × 2000 | 1490 |
| HX1T 30 NP | 7 | 30 | 1490 | ||||
| Models For High Pressure | |||||||
| HX2T 75 HP | 278 | 15 | 298 | 12 | 75 | 2755 × 1765 × 2040 | 2900 |
| HX2T 100 HP | 400 | 15 | 417 | 12 | 100 | 2755 × 1875 × 2125 | 2900 |
*If you want, I can also add the small “Note” line exactly like the brochure under this table.
Key Features
- 100% Oil-Free Air Compressor
- Environment Friendly
- Compact Self-Contained Package
- Reliable Electronic Control
Note
- All packaged versions include compressor, motor, after cooler, control panel suitably mounted on a deck. Air Dryer & Receiver are optional supplies.
- Self-contained packaged versions include, in addition to the above, a close circuit water cooling system, thus eliminating the need for external water supply.
- FAD (*) and Power Tolerance as per BS - 1571 latest edition.
- The above performances are given at sea level.
- HX1T – Vertical models are with ES 3000 controller.
- HX2T – Horizontal models are with ES 4000 controller.
